Sales Conversion Optimization Project 📈

Deployed Application: Sales Conversion Optimisation Web App

Table of Contents 📑

1. Project Description 📝
2. Project Structure 🏗️
3. Necessary Installations 🛠️
4. Train Pipeline 🚂
5. Continuous Integration Pipeline 🔁
6. Alert Reports 📧
7. Prediction App 🎯
8. Neptune.ai Dashboard 🌊
9. Docker Configuration 🐳
10. GitHub Actions and CML Reports 🛠️
11. Running the Project 🚀

Project Description 🚀

Welcome to the Sales Conversion Optimization Project! 📈 This project focuses on enhancing sales conversion rates through careful data handling and efficient model training. The goal is to optimize conversions using a structured pipeline and predictive modeling.

I've structured this project to streamline the process from data ingestion and cleaning to model training and evaluation. With an aim to empower efficient decision-making, my pipelines include quality validation tests, drift analysis, and rigorous model performance evaluations.

This project aims to streamline your sales conversion process, providing insights and predictions to drive impactful business decisions! 📊✨

Live Demo Walkthrough:

Project Structure 🏗️

Let's dive into the project structure! 📁 Here's a breakdown of the directory:

• steps Folder 📂

  • ingest_data
  • clean_data
  • train_model
  • evaluation
  • production_batch_data
  • predict_prod_data

• src Folder 📁

  • clean_data
  • train_models

• pipelines Folder 📂

  • training_pipeline
  • ci_cd_pipeline

• models Folder 📁

  • saved best H20.AI model

• reports Folder 📂

  • Failed HTML Evidently.ai reports

• production data Folder 📁

  • Production batch dataset

• Other Files 📄

  • requirements.txt
  • run_pipeline.py
  • ci-cd.py

This organized structure ensures a clear separation of concerns and smooth pipeline execution. 🚀

Necessary Installations 🛠️

To ensure the smooth functioning of this project, several installations are required:

1. Clone this repository to your local machine.

   git clone https://github.com/VishalKumar-S/Sales_Conversion_Optimization_MLOps_Project
   cd Sales_Conversion_Optimization_MLOps_Project

2. Install the necessary Python packages.

   pip install -r requirements.txt

3. ZenML Integration

   pip install zenml["server"]
   zenml init      #to initialise the ZenML repository
   zenml up

4. Neptune Integration

   zenml experiment-tracker register neptune_experiment_tracker --flavor=neptune \
   --project="$NEPTUNE_PROJECT" --api_token="$NEPTUNE_API_TOKEN"

   zenml stack register neptune_stack \
   -a default \
   -o default \
   -e neptune_experiment_tracker \
   --set

Make sure to install these dependencies to execute the project functionalities seamlessly! 🌟

Train Pipeline 🚂

In this pipeline, it covers various steps involved in the ML lifecycle, ensuring our system is always reliable! 🛤️ Here's the process breakdown:

1. run_pipeline.py: Initiates the training pipeline.
2. steps/ingest_Data: Ingests the data, sending it to the data_validation step.
3. data_validation step: Conducts validation tests and transforms values.
4. steps/clean_Data: Performs out data preprocessing logic.
5. data_Drift_validation step: Conducts data drift tests.
6. steps/train_model.py: Utilizes h2o.ai AUTOML for model selection.
7. src/train_models.py: Implements the best model on the cleaned dataset.
8. model_performance_Evaluation.py: Assesses model performance on a split dataset.
9. steps/alert_report.py: Here, if any of the validation test suites, didn't meet the threshold condition, email will be sent to the user, along with the failed Evidently.AI generated HTML reports.

Each step is crucial in refining and validating our model. All aboard the train pipeline! 🌟🚆

Continuous Integration Pipeline ⚙️

The continuous integration pipeline focuses on the production environment and streamlined processes for deployment. 🔄

Here's how it flows:

1. ci-cd.py: Triggered to initiate the CI/CD pipeline.
2. steps/production_batch_data: Accesses production batch data from the Production_data folder
3. pipelines/ci_cd_pipeline.py: As we already discussed earlier, we conduct Data Quality, Data stability tests, Data drift, model performance validation tests as previously we did, if threshold fails, email reports are sent.
4. steps/predict_production_Data.py: Utilizes the pre-trained best model to make predictions on new production data. Then, we conduct Model Performance validation as previously we did, if threshold fails, email reports are sent.

This pipeline is crucial for maintaining a continuous and reliable deployment process. 🔁✨

Alert Reports 📧

In my project, email reports are a vital part of the pipeline to notify users when certain tests fail. These reports are triggered by specific conditions during the pipeline execution. Here's how it works:

E-mail Details

Upon data quality or data drift test or model performance validation tests failures, an email is generated detailing:

• Number of total tests performed.
• Number of passed and failed tests.
• Failed test reports attached in HTML format.

Integration with Pipeline Steps

This email functionality is integrated into the pipeline steps via Python scripts (steps/alert_report.py). If a particular test threshold fails, the execution pauses and an email is dispatched. Successful test completions proceed to the next step in the pipeline.

This notification system helps ensure the integrity and reliability of the data processing and model performance at each stage of the pipeline.

We also send failed alert reports via Discord and Slack platforms.

Discord: #failed-alerts

Slack: #sales-conversion-test-failures

Prediction App 🚀

The Prediction App is the user-facing interface that utilises the trained models to make predictions based on user input. 🎯 To run the streamlit application, bash streamlit run app.py

Functionality:

• 🌐 Streamlit Application: User-friendly interface for predictions and monitoring.
• 🚀 Prediction App: Input parameters for prediction with a link to Neptune.ai for detailed metrics.
• 📊 Interpretability Section: Explore detailed interpretability plots, including SHAP global and local plots.
• 📈 Data and Model Reports: View reports on data quality, data drift, target drift, and model performance.
• 🛠️ Test Your Batch Data Section: Evaluate batch data quality with 67 validation tests, receive alerts on failures.

This app streamlines the process of making predictions, interpreting model outputs, monitoring data, and validating batch data.

Prediction App 🚀

User Input Data

• Fields: Impressions, Clicks, Spent, Total_Conversion, CPC.
• Predict button generates approved conversion predictions.
• 🔗 Neptune.ai Metrics

Interpretability Section

• 📝 Detailed Interpretability Report: View global interpretability metrics.
• 🌐 SHAP Global Plot: Visualize SHAP values at a global level.
• 🌍 SHAP Local Plot: Visualize SHAP values for the user-input data in the Prediction App.

Data and Model Reports

• 📉 Data Quality Report: Assess data quality between reference and current data.
• 📊 Data Drift Report: Identify drift in data distribution.
• 📈 Target Drift Report: Monitor changes in target variable distribution.
• 📉 Model Performance Report: Evaluate the model's performance.

Choose Reports

• Check options to generate specific reports.
• Click 'Submit' to view generated reports.

Test Your Batch Data

1. 📂 Dataset Upload: Upload your batch dataset for validation.
2. 📧 Email Alerts: Provide an email for failure alerts.
3. 🔄 Data Validation Progress: 67 tests to ensure data quality.
4. 📊 Visualizations: Scatter plot and residuals plot for validation results.

Step 1: Upload Your Batch Dataset

Step 2: Provide Email Address for Alerts

Step 3: Data Validation Progress

Successful tests validation:

Failed tests validation:

For more details, check the respective sections in the Streamlit app.

This application provides an intuitive interface for users to make predictions and monitoring effortlessly. 📊✨ Explore data-driven insights with ease and confidence! 🚀🔍

Neptune.ai Dashboard 🌊

Neptune.ai offers an intuitive dashboard for comprehensive tracking and management of experiments, model metrics, and pipeline performance. Let's dive into its features:

1. Visual Metrics: Visualize model performance metrics with interactive charts and graphs for seamless analysis. 📈📊
2. Experiment Management: Track experiments, parameters, and results in a structured and organized manner. 🧪📋
3. Integration Capabilities: Easily integrate Neptune.ai with pipeline steps for automated tracking and reporting. 🤝🔗
4. Collaboration Tools: Facilitate teamwork with collaborative features and easy sharing of experiment results. 🤝💬
5. Code and Environment Tracking: Monitor code versions and track environments used during experimentation for reproducibility. 🛠️📦

Necessary Commands:

1. Necessary imports:

   import neptune
   from neptune.types import File
   from zenml.integrations.neptune.experiment_trackers.run_state import get_neptune_run

2. Initiate the neptune run

   neptune_run = get_neptune_run()

3. To track the pandas dataframe:

   neptune_run["data/Training_data"].upload(File.as_html(df))

4. Track HTML reports:

   neptune_run["html/Data Quality Test"].upload("Evidently_Reports/data_quality_suite.html")

5. Track plot and graph visualisations:

   neptune_run["visuals/scatter_plot"].upload(File.as_html(fig1))

6. Track model metrics:

   model["r2"].log(perf.r2())
   model["mse"].log(perf.mse())
   model["rmse"].log(perf.rmse())
   model["rmsle"].log(perf.rmsle())
   model["mae"].log(perf.mae())

Neptune.ai Dashboard runs:

Neptune.ai Dashboard Code files:

Neptune.ai Dashboard Datasets:

Neptune.ai Dashboard visualisations:

Neptune.ai Dashboard HTML reports:

Neptune.ai Dashboard models:

Neptune.ai Dashboard model metrics:

Access my Neptune.ai Dashboard here

Neptune.ai enhances the project by providing a centralized platform for managing experiments and gaining deep insights into model performance, contributing to informed decision-making. 📊✨

Docker Configuration 🐳

Docker is an essential tool for packaging and distributing applications. Here's how to set up and use Docker for this project:

Running the Docker Container: Follow these steps to build the Docker image and run a container:

```bash
docker build -t my-streamlit-app .
docker run -p 8501:8501 my-streamlit-app
```

Best Practices: Consider best practices such as data volume management, security, and image optimization.

GitHub Actions and CML Reports 📊

My project integrates GitHub Actions for Continuous Integration and Continuous Deployment (CI/CD), automating testing and deployment processes whenever changes are pushed to the repository.

Workflow Overview 🔍

The CI/CD pipeline automatically runs on every code push, performing the following steps:

Environment Setup 🛠️

1. Checks out the latest code
2. Installs all dependencies from requirements.txt

ZenML Configuration 📊

1. Registers the Neptune experiment tracker
2. Creates and sets the ZenML stack with Neptune integration

Pipeline Execution 🚀

1. Runs the CI/CD pipeline script with secure environment variables
2. Handles sensitive information (email password, API tokens) using GitHub Secrets

CML Reporting 📈

1. Generates visual reports using Continuous Machine Learning (CML)
2. Creates prediction scatter plots (model predictions against actual conversions) and residuals plots (differences between predicted and actual values).
3. Publishes results as comments directly in GitHub

🌟 So my CI/CD approach eliminates manual testing and deployment steps and provides visual feedback on model performance and these reports enhance transparency and provide crucial insights into model performance! 🌟

Running the Project 🚀

Follow these steps to run different components of the project:

1. Training Pipeline:

   • To initiate the training pipeline, execute

    python run_pipeline.py

2. Continuous Integration Pipeline:

   • To execute the CI/CD pipeline for continuous integration, run

   python run_ci_cd.py

3. Streamlit Application:

   • Start the Streamlit app to access the prediction interface using,

   streamlit run app.py

Each command triggers a specific part of the project. Ensure dependencies are installed before executing these commands. Happy running! 🏃‍♂️✨
